How to Use Waypoint Pro on DJI Inspire 3?

• Learn how to use Waypoint Pro on the DJI Inspire 3 for precise flight-route planning and aerial cinematography;

• Explore the two available modes: Repeatable Routes for automated paths and 3D Dolly for dynamic, cinematic shots;

• Understand how to create and customise flight routes using the DJI Pilot 2 app;

• Find instructions for adding, editing, and removing waypoints, both manually and automatically;

• Learn how to apply global and individual waypoint settings, including altitude, speed, and gimbal adjustments;

• Follow steps to save and execute flight routes from the Library for seamless operation;

• Discover how to pause or exit Waypoint Pro during a flight for maximum control and flexibility.

Waypoint Pro is a powerful tool designed to elevate your aerial cinematography with the DJI Inspire 3. This feature allows you to plan and execute customised flight routes, enabling the aircraft to perform precise movements and actions automatically.

With two advanced modes—Repeatable Routes and 3D Dolly—you can achieve professional-grade shots effortlessly.

This guide walks you through the process of creating flight routes, adding waypoints, adjusting settings, and executing your plans for smooth and consistent results.

Access Waypoint Pro

1. Tap the flight route button in either the camera view or map view.

2. In camera view, tap the flight route icon, then select "Create" under the Library panel to create a flight route.

3. Use the map view to plot and customise the flight route.

Adding waypoints

• Manual Add Waypoint: Press the C1 button on the remote controller to add a waypoint and C2 to delete the current waypoint.

• Auto Add Waypoint: Enable Auto Add Waypoint in DJI Pilot 2 to record the aircraft's position, orientation, gimbal angle, and other data at regular intervals.

Flight Route Editor

Editing waypoints:

1. Enable the Waypoint Editing Switch to add or drag waypoints directly on the map. Tap again to disable editing.

2. Use the "Reverse Flight Route" option to swap the start and endpoint of the route.

3. Clear all waypoints with "Clear Waypoints".

4. Delete individual waypoints with "Delete Selected Waypoints".

Settings:

• Flight Route Settings: Apply global settings such as control mode, speed, altitude, route type, and actions upon route completion.

• Individual Waypoint Settings: Select specific waypoints to adjust speed, altitude, gimbal yaw/pitch angle, and actions.

• General Settings: Configure the flight route name, altitude mode, waypoint count, and overall route length. The upper-left corner of the map view displays total route length, estimated flight time, waypoint count, and photo quantity.

Saving and executing flight routes

1. Save the route: Tap "Save" to store the route settings in the Library.

2. Execute the route: Select a saved route from the Library and tap "Execute" to open the Waypoint Pro settings panel.

3. Choose between: "Repeatable Routes" or "3D Dolly" modes and set parameters accordingly.

Mode descriptions

• Repeatable Routes: The aircraft follows the preset route until it ends.

• 3D Dolly:

  • Auto Mode: Automatically adjusts the aircraft’s orientation and gimbal pan/tilt based on the route.

  • Manual Mode: Allows manual control of orientation and gimbal pan/tilt using the control sticks and dials.

Pausing and exiting the flight

1. Pause the flight: Tap the pause icon in the flight route progress panel or press the Flight Pause button on the remote controller.

2. Exit Waypoint Pro: Tap the flight route icon in the camera view to exit the Waypoint Pro mode.

Summary

By following the steps in this guide, you can plan, customise, and execute flight paths using Repeatable Routes or 3D Dolly modes for seamless and professional results.

Whether automating your shots or taking manual control, Waypoint Pro ensures flexibility and precision for any scenario. For further assistance or questions, contact heliguy™.
